Dl40 slave to slc channel 0 -7, Dl40 plus slave to plc-5 channel 0, Dl40 plus slave to slc channel 0 – Rockwell Automation 2706-LV2S_LV4S DL40 PLUS SLAVE USER MANUAL User Manual
Page 24
Publication 2706-6.3
Installation and Startup
3-7
DL40 Plus Slave to PLC-5 Channel 0
Connect the DL40 Plus Slave to a PLC-5 Channel 0 port as shown
below. You can also use programming cable (Catalog No. 2706-
NC12).
DL40 Plus Slave to SLC Channel 0
Connect the DL40 Plus Slave to an SLC Channel 0 port as shown
below. You can also use programming cable (Catalog No. 2706-
NC12).
.
DL40 Plus Slave
6
4
#
2
20
7
8
3
PLC-5 Channel 0
25 Pin D Shell Connector
DCD
RXD
TXD
DTR
Common
DSR
RTS
CTS
RS-232 Port
1
Chassis Ground
6
7
8
3
4
5
1
2
9
Shield
No Connection
TXD
RXD
No Connection
Signal Common
DSR
RTS
CTS
No Connection
DL40 Plus Slave
6
7
8
3
4
5
1
2
SLC Channel 0
9-Pin Connector
DCD
RXD
TXD
DTR
Common
DSR
RTS
CTS
RS-232 Port
6
7
8
3
4
5
1
2
9
Shield
No Connection
TXD
RXD
No Connection
Signal Common
DSR
RTS
CTS
No Connection
