Power connections, Power connections -12 – Rockwell Automation 2706-LV2S_LV4S DL40 PLUS SLAVE USER MANUAL User Manual
Page 29
Publication 2706-6.3
3-12
Installation and Startup
Power Connections
Before making power connections, make sure that the power is turned
off. The DL40 Plus Slave requires 100-240Volts AC, 50/60 Hz, 0.60 -
0.25 Amperes.
Important: Make sure all DIP switches are properly set as described
in Chapter 2 before applying power.
!
ATTENTION: Improper wiring of the power
connections may result in damage to the DL40.
Green
(Green/Yellow)
White
(Blue)
L2N
L1
Black
(Brown)
