Removal -4, Removal – Rockwell Automation 1747-SN Remote I/O Scanner User Manual
Page 38
Publication 1747-UM013B-EN-P - January 2005
3-4 Installation and Wiring
Removal
1. Disconnect power.
2. Remove all cabling.
3. Press the releases at the top and bottom of the module and slide
the module out of the chassis slot.
4. Cover all unused slots with the Card Slot Filler, Catalog Number
1746-N2.
Card Guide
Module Release
Cable Tie
