I/I/O From/To Lists
Appendix B
BĆ8
I/O From/To List for Figure 6.15
Operator Station 3
From To
A100 Left RUN button (NC) contact)
A101 Right RUN button (NO) contact
A102 Left Active jumper conection
A10B 2L2
B100 Right RUN button (NC) contact
B101 Left RUN button (NO) contact
B102 Right Active jumper conection
B10B 2L2
I/O From/To List for Figure 6.16
Operator Station 4
From To
A103 Left RUN button (NC) contact)
A104 Right RUN button (NO) contact
A105 Left Active jumper conection
B103 Right RUN button (NC) contact
B104 Left RUN button (NO) contact
B105 Right Active jumper conection
I/O From/To List for Figure 6.17
Main and Auxiliary Valve Stem,
Motion Detector, and Air Pressure Switches
From To
A200 Switch on Main Valve Stem A
A201 Motion Detector A
A201 B201 (make this connection when NOT using Motion Detector B)
A202 Air Pressure Switch A
A202 B202 (make this connection when NOT using AIr Pressure Switch B)
A207 Switch on Auxiliary Valve Stem A
B200 Switch on Main Valve Stem B
B201 Motion Detector B (if used)
B202 AIr Pressure Switch B (if used)
B207 Switch on Auxiliary Valve Stem B
