Appendix
E
Logic Command/Status Words
Appendix E provides the definitions of the Logic Command/Logic Status
words that are used for some drives that can be connected to the
1769-SM1. If your product is not included here, refer to its documentation.
Logic Command Word
PowerFlex 7-Class Drives (except PowerFlex 700S)
Logic Bits
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Command Description
x Stop
(1)
0 = Not Stop
1 = Stop
x Start
(1)(2)
0 = Not Start
1 = Start
x Jog 0 = Not Jog
1 = Jog
x Clear Faults 0 = Not Clear Faults
1 = Clear Faults
x x Direction 00 = No Command
01 = Forward Command
10 = Reverse Command
11 = Hold Direction Control
x Local
Control 0 = No Local Control
1 = Local Control
x MOP
Increment 0 = Not Increment
1 = Increment
x x Accel Rate 00 = No Command
01 = Accel Rate 1 Command
10 = Accel Rate 2 Command
11 = Hold Accel Rate
x x Decel Rate 00 = No Command
01 = Decel Rate 1 Command
10 = Decel Rate 2 Command
11 = Hold Decel Rate
x x x Reference
Select
(3)
000 = No Command
001 = Ref. 1 (Ref A Select)
010 = Ref. 2 (Ref B Select)
011 = Ref. 3 (Preset 3)
100 = Ref. 4 (Preset 4)
101 = Ref. 5 (Preset 5)
110 = Ref. 6 (Preset 6)
111 = Ref. 7 (Preset 7)
x MOP
Decrement 0 = Not Decrement
1 = Decrement
(1)
A “0 = Not Stop” condition (logic 0) must first be present before a “1 = Start” condition will start the drive. The Start
command acts as a momentary Start command. A “1” will start the drive, but returning to “0” will not stop the drive.
(2)
This Start will not function if a digital input (parameters 361-366) is programmed for 2-Wire Control (option 7, 8 or 9).
(3)
This Reference Select will not function if a digital input (parameters 361-366) is programmed for “Speed Sel 1, 2 or 3”
(option 15, 16 or 17). Note that Reference Select is “Exclusive Ownership” - see drive User Manual for further information.
