8-6 Troubleshooting
Events
Many events in the Event queue occur under normal operation. If you
encounter unexpected communications problems, the events may help
you or Allen-Bradley personnel troubleshoot the problem. The following
events may appear in the event queue:
Code Event Description
1 No Event Empty event queue entry.
2 DPI Bus Off Flt A bus-off condition was detected on DPI. This event may be
caused by loose or broken cables or by noise.
3 Ping Time Flt A ping message was not received on DPI within the specified
time.
4 Port ID Flt The debounced DPI Pin ID is read as zero or seven after the
module has completed startup.
5 Port Change
Flt The debounced DPI Pin ID has changed after the module has
completed startup.
6 Host Sent
Reset The drive sent a reset event message.
7 EEPROM Sum
Flt The startup sequence detected corrupt EEPROM storage in
the module.
8 Online @ 125
kbps The module detected that the drive is communicating at 125
kbps.
9 Online @ 500
kbps The module detected that the drive is communicating at 500
kbps.
10 Bad Host Flt The module is connected to an incompatible drive.
11 Dup. Port Flt Another peripheral with the same port number is already in
use.
12 Type 0 Login The module has logged in for type 0 control.
13 Type 0 Time
Flt The module has not received a type 0 status message within
the specified time.
14 DL Login The module has logged in for a Datalink.
15 DL Reject Flt The drive rejected an attempt to log in to a Datalink because
the Datalink is not supported or is used by another peripheral.
16 DL Time Flt The module has not received a Datalink message within the
specified time.
17 Reserved —
18 Control
Disabled The module has sent a “Soft Control Disable” command to the
drive.
19 Control
Enabled The module has sent a “Soft Control Enable” command to the
drive.
20 Message
Timeout A Client-Server message sent by the module was not
completed.
21 Flt Cfg Error The module detected a 32-bit fault configuration reference or
Datalink when the drive expects a 16-bit value.
22 App Updated Startup sequence detected new application firmware in the
flash candidate area.
23 Net Comm
Fault The module detected a communications fault on the network.
24 Net Sent
Reset The module received a reset from the network.
25 Net Close Flt An I/O connection from the network to the module was closed.
