Using the pcbridge software – Rockwell Automation 1771-DMC_DMC1_DMC4_DXPS Control Coprocessor User Manual User Manual
Page 279
Appendix
D
D-1
Using the PCBridge Software
This appendix provides additional information about using the PCBridge
software. Getting started using the software is covered in Chapters 3
and 4.
The PCBridge software is a PC-based development system for OS-9/680x0
applications. Through this software, you can access the OS-9 operating
system. The PCBridge software provides a C language cross-compiler, r68
assembly and linking tools, a debugger, and a complete set of
program-development utilities. These utilities include
terminal
emulation
text and binary file transfers between PC-DOS and OS-9
file
manipulation
session logging utilities.
The following are some of the PCBridge options that you can configure.
You first go to the configuration options menu. See Figure D.1.
Figure D.1
Configuration Options Menu
Appendix Objectives
About PCBridge Software
Configuration Options
