API Library of Routines
Appendix B
DTL_READ_W_IDX
B-67
Reads any elements of a file, one element at a time, from the PLC-5
programmable controller to the control-coprocessor memory using only
one data definition.
Important: To use this function call, you must have the versions of the
ABLIB.L and CORPRO.H files that accompany Series A Revision D
(1.20) or later of the Program Development Software. Contact Allen-
Bradley Global Technical Support Services at (216) 646-6800 if you need
these updates.
C Syntax
#include
unsigned DTL_READ_W_IDX (name_id, variable, iostat, index)
unsigned name_id;
void *variable;
unsigned *iostat;
unsigned index;
Parameters
name_id
DTL_C_DEFINE returns this handle when the data file to be read
is defined.
variable
Address of a buffer that stores the data read from the file. Ensure that
the declared variable is the right type to match the data size that was
specified in DTL_C_DEFINE.
iostat
This parameter returns a final completion status. Possible completion
status values are:
Value Meaning
0 DTL_SUCCESS = operation completed successfully
27 DTL_E_NOATMPT = I/O operation not attempted; see status variable for reason
41 DTL_E_CNVT = dataĆconversion error
xxx ¬ PCCC_E_xxx = operation refused by the PLCĆ5 programmable controller
¬ See Table B.A for PCCC errors.
index
This parameter specifies the element or structure level of the data-file
item to be read.
DTL_READ_W_IDX
