Installing the control coprocessor – Rockwell Automation 1771-DMC_DMC1_DMC4_DXPS Control Coprocessor User Manual User Manual
Page 19

Chapter
2
2-1
Installing the Control Coprocessor
This chapter provides instructions on how to install your
control-coprocessor main module and serial expander module.
For information on:
See page:
What you need to install
your control coprocessor
2Ć1
Selecting a power supply
2Ć2
Preventing ESD damage
2Ć2
Installing the battery
2Ć3
Installing the keying bands
2Ć5
Setting switch
configurations
2Ć6
Installing the control
coprocessor
2Ć7
Applying power to the
control coprocessor
2Ć11
Removing the control
coprocessor
2Ć11
You need the following items for installation:
control
coprocessor
serial expander module (optional)
connector header (when using direct-connect mode)
four connecting screws and spacers (when using direct-connect mode)
lithium battery, battery cover, and mounting screw
ESD grounding wrist strap
chassis keying bands
power
supply
chassis (properly grounded)
Chapter Objectives
What You Need to Install
Your Control Coprocessor
Introduction
Installing the Control
Coprocessor
Getting Started with the
Control Coprocessor
Using the Programming
Environment
Developing Programs
Interpreting Fault
Codes and Displays
Using the Ethernet
Interface
Using the Serial Ports
