API Library of Routines
Appendix B
DTL_C_DEFINE
B-41
CC Data Type: Is: CC Data Type: Is:
RAW no conversion LONG int (signed)
BYTE char (signed) ULONG unsigned int
UBYTE unsigned char FLOAT float
WORD ¬ short (signed) DOUBLE double
UWORD unsigned short
¬ Default is WORD
[access type]
Optional; legal access rights are:
* READ = read only
* MODIFY = read or write
Default is modify.
Returns
Status Symbolic Name Meaning
0 DTL_SUCCESS Operation successful
03 DTL_E_DEFBAD2 Invalid number of elements to DEFINE
04 DTL_E_DEFBAD3 Invalid data type
05 DTL_E_DEFBAD4 Invalid access rights
09 DTL_E_DEFBADN Invalid number of DEFINE parameters
11 DTL_E_FULL Data DEFINE table is full
16 DTL_E_INVTYPE Data is invalid type for operation
19 DTL_E_NOINIT DEFINE table not initialized
31 DTL_E_TOOBIG Data item greater than maximum allowed
38 DTL_E_DFBADADR Bad DEFINE address
40 DTL_E_INPTOOLONG DEFINE input string too long
Description
Use the DTL_C_DEFINE function to add a data definition to the table of
data definitions for the calling task. The DTL_C_DEFINE routine returns
a handle with which the calling task can refer to the data item in
subsequent DTL calls. You must use the DTL_C_DEFINE function to
create an entry for each contiguous range of data-table locations you need.
C Example
unsigned fred; /*handle used in later DTL_READ_W or
DTL_WRITE_W calls*/
unsigned status;
status = DTL_C_DEFINE (&fred,“N10:2,10,WORD,READ”);
