Channel Configuration, Data, and Status 4-13
Table 4.3 Data Formats for RTD Temperature Ranges for 0.25 and 1.0 mA Excitation
Current
Table 4.4 Data Format for 500
Ω
Ω
Ω
Ω
Platinum RTD (385)
Table 4.5 Data Format for 1000
Ω
Ω
Ω
Ω
Platinum RTD (385)
Table 4.6 Data Format for 500
Ω
Ω
Ω
Ω
Platinum RTD (3916)
Table 4.7 Data Format for 1000
Ω
Ω
Ω
Ω
Platinum RTD (3916)
Table 4.8 Data Format for 604
Ω
Ω
Ω
Ω
Nickel Iron RTD (518)
RTD Input Type
Data Format
Engineering Units x 1
Engineering Units x 10
Scaled-for-PID Proportional Counts
(Default)
0.1°C
0.1°F
1.0°C
1.0°F
100
Ω
Platinum (385)
-2000 to +8500
-3280 to +15620
-200 to +850
-328 to +1562
0 to 16383
-32768 to 32767
200
Ω
Platinum (385)
-2000 to +6300
-3280 to + 6300
-200 to +630
-328 to +630
0 to 16383
-32768 to 32767
100
Ω
Platinum (3916)
-2000 to +6300
-3280 to +6300
-200 to +630
-328 to +630
0 to 16383
-32768 to 32767
200
Ω
Platinum (3916)
-2000 to +6300
-3280 to +6300
-200 to +630
-328 to +630
0 to 16383
-32768 to 32767
120
Ω
Nickel (672)
-800 to +2600
-3280 to +5000
-80 to +260
-328 to +500
0 to 16383
-32768 to 32767
120
Ω
Nickel (618)
(1)
-1000 to +2600
-3280 to +5000
-100 to +260
-328 to +500
0 to 16383
-32768 to 32767
10
Ω
Copper (426)
-1000 to +2600
-3280 to +5000
-100 to +260
-328 to +500
0 to 16383
-32768 to 32767
(1) Actual value at 0 °C is 100
Ω
per DIN standard.
Excitation Current Data Format
Engineering Units x 1
Engineering Units x 10
Scaled-for-PID Proportional Counts
(Default)
0.1 C
0.1°F
1.0°C
1.0°F
0.25 mA
-2000 to +8500
-3280 to +15620
-200 to +850
-328 to +1562 0 to 16383
-32768 to 32767
1.0 mA
-2000 to +3900
-3280 to +6980
-200 to +390
-328 to +698
0 to 16383
-32768 to 32767
Excitation Current Data Format
Engineering Units x 1
Engineering Units x 10
Scaled-for-PID Proportional Counts
(Default)
0.1 C
0.1°F
1.0°C
1.0°F
0.25 mA
-2000 to +8500
-3280 to +15620
-200 to +850
-328 to +1562 0 to 16383
-32768 to 32767
1.0 mA
-2000 to +500
-3280 to +1220
-200 to +50
-328 to +122
0 to 16383
-32768 to 32767
Excitation Current Data Format
Engineering Units x 1
Engineering Units x 10
Scaled-for-PID Proportional Counts
(Default)
0.1 C
0.1°F
1.0°C
1.0°F
0.25 mA
-2000 to +6300
-3280 to +11660
-200 to +630
-328 to +1166 0 to 16383
-32768 to 32767
1.0 mA
-2000 to +3800
-3280 to +6980
-200 to +380
-328 to +698
0 to 16383
-32768 to 32767
Excitation Current Data Format
Engineering Units x 1
Engineering Units x 10
Scaled-for-PID Proportional Counts
(Default)
0.1 C
0.1°F
1.0°C
1.0°F
0.25 mA
-2000 to +6300
-3280 to +11660
-200 to +630
-328 to +1166 0 to 16383
-32768 to 32767
1.0 mA
-2000 to +500
-3280 to +1220
-200 to +50
-328 to +122
0 to 16383
-32768 to 32767
Excitation Current Data Format
Engineering Units x 1
Engineering Units x 10
Scaled-for-PID Proportional Counts
(Default)
0.1°C
0.1°F
1.0°C
1.0°F
0.25 mA
-2000 to +2000
-3280 to +3920
-200 to +200
-328 to +392
0 to 16383
-32768 to 32767
1.0 mA
-2000 to +1800
-3280 to +3380
-200 to +180
-328 to +338
0 to 16383
-32768 to 32767
