3-6 Preliminary Operating Considerations

Effective Resolution

The effective resolution for an input channel depends upon the filter frequency
selected for that channel. The following table displays the effective resolution
for the various input types and filter frequencies:

Table 3.2 Effective Resolution for RTD and Resistance Inputs
Input Type

Filter Frequency
28 Hz

50/60 Hz

800 Hz

6400 Hz

100

Pt RTD (385)

(1)

± 0.1°C
(± 0.1°F)

± 0.1°C
(± 0.1°F)

± 0.2°C
(± 0.4°F)

± 0.8°C
(± 1.4°F)

200

Pt RTD (385)

(1)

± 0.1°C
(± 0.1°F)

± 0.1°C
(± 0.1°F)

± 0.2°C
(± 0.4°F)

± 0.8°C
(± 1.4°F)

500

Pt RTD (385)

(1)

± 0.1°C
(± 0.1°F)

± 0.1°C
(± 0.1°F)

± 0.2°C
(± 0.4°F)

± 0.8°C
(± 1.4°F)

1000

Pt RTD (385)

(1)

± 0.1°C
(± 0.1°F)

± 0.1°C
(± 0.1°F)

± 0.2°C
(± 0.4°F)

± 0.8°C
(± 1.4°F)

100

Pt RTD (3916)

(1)

± 0.1°C
(± 0.1°F)

± 0.1°C
(± 0.1°F)

± 0.2°C
(± 0.4°F)

± 0.8°C
(± 1.4°F)

200

Pt RTD (3916)

(1)

± 0.1°C
(± 0.1°F)

± 0.1°C
(± 0.1°F)

± 0.2°C
(± 0.4°F)

± 0.8°C
(± 1.4°F)

500

Pt RTD (3916)

(1)

± 0.1°C
(± 0.1°F)

± 0.1°C
(± 0.1°F)

± 0.2°C
(± 0.4°F)

± 0.8°C
(± 1.4°F)

1000

Pt RTD (3916)

(1)

± 0.1°C
(± 0.1°F)

± 0.1°C
(± 0.1°F)

± 0.2°C
(± 0.4°F)

± 0.8°C
(± 1.4°F)

10

Cu RTD (426)

(1) (2)

± 0.1°C
(± 0.1°F)

± 0.1°C
(± 0.2°F)

± 0.4°C
(± 0.7°F)

± 1.0°C
(± 1.8°F)

120

Ni RTD (618)

(1)

(3)

± 0.1°C
(± 0.1°F)

± 0.1°C
(± 0.1°F)

± 0.1°C
(± 0.1°F)

± 0.3°C
(± 0.5°F)

120

Ni RTD (672)

(1)

± 0.1°C
(± 0.1°F)

± 0.1°C
(± 0.1°F)

± 0.1°C
(± 0.1°F)

± 0.3°C
(± 0.5°F)

604

NiFe RTD (518)

(1)

± 0.1°C
(± 0.1°F)

± 0.1°C
(± 0.1°F)

± 0.1°C
(± 0.1°F)

± 0.3°C
(± 0.5°F)

150

Resistance Input ± 0.01

± 0.01

± 0.02

± 0.08

500

Resistance Input ± 0.1

± 0.1

± 0.1

± 0.4

1000

Resistance Input ± 0.1

± 0.1

± 0.2

± 0.6

3000

Resistance Input ± 0.1

± 0.1

± 0.3

± 1.0

(1) The digits following the RTD type represent the temperature coefficient of resistance (

α

), which is defined as

the resistance change per ohm per °C. For instance, Platinum 385 refers to a platinum RTD with

α

= 0.00385

ohms/ohm -°C or simply 0.00385 /°C.

(2) Actual value at 0°C is 9.042

per SAMA standard RC21-4-1966.

(3) Actual value at 0°C is 100

per DIN standard.
