Page 107: Appendix

background image

1

Publication 1746-UM003A-EN-P

Appendix

B

Configuration Worksheet for RTD/Resistance
Module

See Chapter 4 for worksheet procedure.

11

12

14

15

13

9

10

8

6

7

4

5

2 1 0

3

Bit Number

Channel 0

Channel 1

Channel 2

Channel 3

Input Type Select
Data Format Select
Broken Input Select
Temperature Units Select
Filter Frequency Select

Channel Enable
Excitation Current Select
Calibration Disable
Lead R Enable

Channel 4

Channel 5

Channel 6

Channel 7

Bit Definitions:
Bits 0 through 3 Input Type Select

0000 = 100

Pt. (385)

0001 = 200

Pt. (385)

0010 = 500

Pt. (385)

0011 = 1000

Pt. (385)

0100 = 100

Pt. (3916)

0101 = 200

Pt. (3916)

0110 = 500

Pt. (3916)

0111 = 1000

Pt. (3916)

1000 = 10

Cu (426)

(1)

1001 = 120

Ni (618)

(2)

1010 = 120

Ni (672)

1011 = 604

Ni-Fe (518)

1100 = 150

Potentiometer

1101= 500

Potentiometer

1110= 1000

Potentiometer

1111= 3000

Potentiometer

Bits 4 and 5

Data Format Select

00 = engineering units, x1

(3)

01 = engineering units, x10

(4)

10 = scaled-for-PID (0 to 16383)
11 = proportional counts (-32768 to +32767)

Bits 6 and 7

Broken Input Select

00 = zero

01 = upscale

10 = downscale

11 = lnvalid

Bit 8

Temperature Units
Select

0 = degrees Celsius

1 = degrees Fahrenheit

Bits 9 and 10

Filter Frequency Select 00 = 28 Hz

01 = 50/60 Hz

10 = 800 Hz

11 = 6400 Hz

Bit 11

Channel Enable

0 = channel disabled

1 = channel enabled

Bit 12

Excitation Current
Select

0 = 1.0 mA

1 = 0.25 mA

Bit 13

Cal. Disable

0 = enable calibration
(default)

1 = disable calibration

Bits 14 and 15

Lead R Enable

00 = Disable, 01 = Periodic, 10 = Always, 11 = Invalid

(1) Actual value at °C is 9.042

per SAMA standard RC21-4-1966.

(2) Actual value at 0°C is 100

per DIN standard.

(3) Values are in 0.1° /step or 0.1

/step for all resistance input types, except 150

. For the 150

resistance input type, the values are in 0.01

/step.

(4) Values are in 1° /step or 1

/step for all resistance input types, except 150

. For the 150

resistance input type, the values are in 0.1

/step.
