Publication 1746-UM003A-EN-P
1-6 Overview
Figure 1.2 RTD Module Hardware
Table 1.4 Hardware Features
General Diagnostic Features
The RTD module contains diagnostic features that can be used to help you
identify the source of problems that may occur during power up or during
normal channel operation. These power-up and channel diagnostics are
explained in Chapter 6, Module Diagnostics and Troubleshooting.
The RTD module communicates to the SLC 500 processor through the
parallel backplane interface and receives +5V dc and +24V dc power from the
SLC 500 power supply through the backplane. No external power supply is
required. You may install as many RTD modules in your system as the power
supply can support, as shown in the illustration below.
INPUT SIGNAL RANGES
R
TD TYPES:
PLA
TINUM,
COPPER
NICKEL,
NICKEL - IR
ON
RESIST
ANCE (OHMS):
150,
500,
1000,
3000
MADE IN U
.S.A
SC P/N:
9060018-01
SC S/N:
167076
SC MFD:
0020
B
A
CKPLANE REQ
UIREMENTS:
55mA @ 24VDC,
100mA @ 5VDC
R
TD / resistance INPUT MODULE
SLC 500
1746-NR8
A
1.00
FRN
SER
CA
T
WIN
(21) 1G0AA2ZT
(21) 1G0AA2ZT
LISTED
1P00
IND CONT EQ
.
FOR HAZ LOC
CL I,
DIV2 GP ABCD
C
U
L
®
U
L
®
RTD / resistance
INPUT
MODULE
CHANNEL
ST ATUS
0 4
1 5
2 6
3 7
150
6
7
5
1
2
3
4
RTD 0
Sense 0
Return 0
RTD 1
Sense 1
Return 1
RTD 2
Sense 2
Return 2
RTD 3
Sense 3
Return 3
RTD 4
Sense 4
Return 4
RTD 5
Sense 5
Return 5
RTD 6
Sense 6
Return 6
RTD 7
Sense 7
Return 7
1746-NR8
Item
Description
Function
1
Channel Status LED
Indicators (green)
Displays operating and fault status of
channels 0, 1, 2, 3, 4, 5, 6, and 7
2
Module Status LED (green)
Displays module operating and fault status
3
Removable Terminal Block
Provides physical connection to input devices
(Catalog # 1746-RT35)
4
Cable Tie Slots
Secures wiring from module
5
Door Label
Provides terminal identification
6
Side Label (Nameplate)
Provides module information
7
Self-Locking Tabs
Secures module in chassis slot
