A-2 Specifications
Environmental Specifications
Input Specifications
Operating Temperature
0°C to +60°C (+32°F to +140°F)
Storage Temperature
-40°C to +85°C (-40°F to +185°F)
Relative Humidity
5% to 95% (without condensation)
Hazardous Environment Classification
Class I, Division 2
Agency Certification
(when product or packaging is marked)
UL and CSA Class I,
Division 2 Groups A, B, C, D certified
CE compliant for all applicable directives
RTD Types
platinum, nickel, nickel iron, copper
(For additional information on RTD types, see page A-3.)
Temperature Scale
(Selectable)
C or F and 0.1 C or 0.1 F
Resistance Scale
(Selectable)
1
Ω
or 0.1
Ω
for all resistance ranges except 150
Ω
; or 0.1
Ω
or
0.01
Ω
for 150
Ω
potentiometer.
Input Step Response
See channel step response, page 3-5.
Input Resolution and
Repeatability
See RTD and resistance device compatibility tables on page 1-3.
Display Resolution
See Channel Data Word Resolution table on page 4-14.
Module Update Time
See Chapter 3, Update Time, page 3-10.
Channel Turn-On Time
Requires up to one module update time plus 125 milliseconds x
the number of unique input type and excitation current
combinations.
Channel Turn-Off Time
Requires up to one module update time.
Reconfiguration Time
Requires up to one module update time plus 125 milliseconds x
the number of unique input type and excitation current
combinations.
RTD Excitation Current
Two current values are user-selectable:
0.25 mA - Recommended for use with higher resistance ranges
for both RTDs and direct resistance inputs (1000
Ω
RTDs and
3000
Ω
resistance input). Refer to RTD manufacturer for
recommendations.
1.0 mA - Recommended to use for all other RTD and direct
resistance inputs, except 1000
Ω
RTDs and 3000
Ω
resistance
input ranges are limited. Refer to RTD manufacturer for
recommendations.
