Publication 1746-UM003A-EN-P

Specifications A-3

Module Accuracy
RTD Temperature Ranges, Resolution, and Repeatability

Input Type

Temp. Range
(0.25 mA Excitation)

(4)

(4) The temperature range for the 1000

RTD is dependent on the excitation current.

Temp. Range
(1.0 mA Excitation)

(4)

Resolution

Repeatability
(28 Hz, 50/60 Hz)

Platinum (385)

(1)

(1) The digits following the RTD type represent the temperature coefficient of resistance (

α

), which is defined as the resistance change per ohm per °C. For instance, Platinum

385 refers to a platinum RTD with

α

= 0.00385 ohms/ohm ·°C or simply 0.00385 /°C.

100

-200°C to +850°C
(-328°F to +1562°F)

-200°C to +850°C
(-328°F to +1562°F)

0.1°C
(0.1°F)

± 0.2°C
(± 0.4°F)

200

-200°C to +850°C
(-328°F to +1562°F)

-200°C to +850°C
(-328°F to +1562°F)

0.1°C
(0.1°F)

± 0.2°C
(± 0.4°F)

500

-200°C to +850°C
(-328°F to +1562°F)

-200°C to +390°C
(-328°F to +698°F)

0.1°C
(0.1°F)

± 0.2°C
(± 0.4°F)

1000

-200°C to +850°C
(-328°F to +1562°F)

-200°C to +50°C
(-328°F to +122°F)

0.1°C
(0.1°F)

± 0.2°C
(± 0.4°F)

Platinum (3916)

(1)

-200°C to +630°C
(-328°F to +1166°F)

-200°C to +630°C
(-328°F to +1166°F)

0.1°C
(0.1°F)

± 0.2°C
(± 0.4°F)

200

-200°C to +630°C
(-328°F to +1166°F)

-200°C to +630°C
(-328°F to +1166°F)

0.1°C
(0.1°F)

± 0.2°C
(± 0.4°F)

500

-200°C to +630°C
(-328°F to +1166°F)

-200°C to +380°C
(-328°F to +698°F)

0.1°C
(0.1°F)

± 0.2°C
(± 0.4°F)

1000

-200°C to +630°C
(-328°F to +1166°F)

-200°C to +50°C
(-328°F to +122°F)

0.1°C
(0.1°F)

± 0.2°C
(± 0.4°F)

Copper (426)

(1)(2)

(2) Actual value at 0°C is 9.042

per SAMA standard RC21-4-1966.

10

-100°C to +260°C
(-328°F to +500°F)

-100°C to +260°C
(-328°F to +500°F)

0.1°C
(0.1°F)

± 0.2°C
(± 0.4°F)

Nickel (618)

(1)(3)

(3) Actual value at 0°C is 100

per DIN standard.

120

-100°C to +260°C
(-328°F to +500°F)

-100°C to +260°C
(-328°F to +500°F)

0.1°C
(0.1°F)

± 0.1°C
(± 0.2°F)

Nickel (672)

(1)

120

-80°C to +260°C
(-328°F to +500°F)

-80°C to +260°C
(-328°F to +500°F)

0.1°C
(0.1°F)

± 0.1°C
(± 0.2°F)

Nickel Iron (518)

(1)

604

-200°C to +200°C
(-328°F to +392°F)

-200°C to +180°C
(-328°F to +338°F)

0.1°C
(0.1°F)

± 0.1°C
(± 0.2°F)

IMPORTANT

The exact signal range valid for each input type is
dependent upon the excitation current magnitude that you
select when configuring the module. For details on
excitation current, refer to page A-2.
