Module addressing, Module addressing -2 – Rockwell Automation 1746-NR8 SLC 500 RTD/Resistance Input Module User Manual User Manual
Page 38

Publication 1746-UM003A-EN-P
3-2 Preliminary Operating Considerations
Module Addressing
The memory map shown in the following illustration displays how the output
and input image tables are defined for the RTD module.
Figure 3.1 Class 1 Memory Map
Channel 0 Configuration Word
Channel 2 Configuration Word
Channel 3 Configuration Word
Channel 4 Configuration Word
Channel 5 Configuration Word
Channel 6 Configuration Word
Channel 7 Configuration Word
Channel 1 Configuration Word
Channel 0 Data Word
Channel 1 Data Word
Channel 2 Data Word
Channel 3 Data Word
Channel 4 Data Word
Channel 5 Data Word
Channel 6 Data Word
Channel 7 Data Word
Word 0
Word 1
Word 2
Word 3
Word 4
Word 5
Word 6
Word 7
O:e.0
O:e.1
O:e.2
O:e.3
O:e.4
O:e.5
O:e.6
O:e.7
Word 0
Word 1
Word 2
Word 3
Word 4
Word 5
Word 6
Word 7
I:e.0
I:e.1
I:e.2
I:e.3
I:e.4
I:e.5
I:e.6
I:e.7
Address
Address
Bit 0
Bit 15
Bit 15
Bit 0
Output
Input
Analog Input
Module
Image Table
Output Image
8 Words
Input Image
8 Words
Output
Scan
Input
Scan
SLC 5/0X
Data Files
Slot e
Slot e
Output Image
Input Image
