6–9
Input, Output and Configuration Files for Analog Modules when used with ControlNet
Publication 1794ĆUM015B-EN-P - May 2001
Definition
Bit
Output
Word
Word 1
Channel 1 Control Word - Control word for setting the function of counter 1.
Bits 00-02
02
01 00
Mode Selection bits
0
0
0
Counting on positive (rising) edge of input signal A. (Up/dwn counting determined by B.)
0
0
1
Quadrature encoder X1
0
1
0
Quadrature encoder X2
0
1
1
Quadrature encoder X4
1
0
0
Counting up on the positive edge of input signal A, and down on positive edge of input signal B.
1
0
1
No count function.
1
1
0
No count function.
1
1
1
No count function.
Bit 03
Preset bit - A positive edge on this bit moves the value in Preset X to Counter X, independent of Preset Enable.
Bit 04
Preset Enable bit - When this bit is set (1), a positive edge on Z preloads Counter X = Preset X, independent of
Cal Enable.
Bit 05
Count Enable bit - When this is set (1), the pulse counter is counting.
Bits 06-08
(06 10)
Calibration Control bits - bits 06, 07 and 08
(06-10)
06 Enable bit - When this bit is set (1), the counter can be calibrated.
07 Direction bit - When this bit set (1), calibration is performed in a negative direction; when reset (0),
calibration is performed in a positive direction.
08 Reset bit - Calibration is acknowledged and a new calibration is enabled on a positive edge on this bit.
Bits 09-10
10
09 Gate Control bits
0
0
No gate function on input G
0
1
Counting only if G is high (active)
1
0
Counting only if G is low (inactive)
1
1
Calibration if G is high (active) and ???
Bits 11-12
(13-14)
12
11 Store Control bits - These bits will trigger a Store only if the channel Store status bit (L0 or L1) is
cleared (0).
0
0
Save the counter value on the positive edge of Z (if Store X = 0)
0
1
Save the counter value on the positive edge of G (if Store X = 0)
1
0
Save the counter value on the negative edge of G (if Store X = 0)
1
1
Save the counter value on the positive edge and negative edge of G (if Store X = 0)
Bit 13
Rollover bit - When set (1), the counter counts up to the preset and then restarts at 0. If this bit is reset (0) (not
rollover), the rollover preset value = FFFF (hex = 65535 (decimal).
Bit 14
Store Reset bit - A positive edge on this bit resets Store X in Signals.
Bit 15
Store Reset bit - A positive edge on this bit resets Preset Detected in Signals.
Word 2
Bits 00-15
Preset 0 - Value to load or compare with counter 0
Word 3
Bits 00-15
Preset 1 - Value to load or compare with counter 1
