Publication 1747-UM006B-EN-P - June 2003
Overview 1-9
Compatible RIO Scanners
Refer to the appropriate scanner manual for details concerning
physical and logical specifications.
Compatible RIO Adapters The 1747-ASB module can physically reside on the RIO link with any
other adapter. The following table lists the adapters available for use
with an RIO link.
Catalog Number Description
1771-SN
(1)
Sub I/O scanner for Mini-PLC
®
-2 and PLC-5 families
1785-L11B
(2) PLC-5/11™ (in scanner mode)
1785-L20B
(2) PLC-5/20™ (in scanner mode)
1785-L30x
(2) PLC-5/30™ (in scanner mode)
1785-L40x
(2) PLC-5/40 (in scanner mode)
1785-L60x (2) PLC-5/60™ (in scanner mode)
1747-SN
(2)(3) SLC Remote I/O Scanner
(1) Revision D or later.
(2) Extended node capability.
(3) Series A scanner does not have block transfer.
Catalog Number Description
1785-L30x
(1)(2) PLC-5/30 (in adapter mode)
1785-L40x
(1)(2) PLC-5/40 (in adapter mode)
1785-L60x (1)(2) PLC-5/60 (in adapter mode)
1771-ASC Remote I/O Adapter Module
1771-ASB
(3)(4) Remote I/O Adapter Module
1771-RIO Remote I/O Interface Module
1771-DCM Direct Communication Module
1747-DCM
(1) Direct Communication Module
2711-xx
(1) PanelView™ Terminal
1336-G2
(1) Remote I/O Adapter for 1336 AC Industrial Drives
1395-NA
(1) Remote I/O Adapter for 1395 DC Industrial Drives
1747-ASB
(1) Remote I/O Adapter Module
(1) Extended node capability.
(2) In adapter mode.
(3) Series A, B, and C.
(4) Extended node capability for Series B and C.
