Appendix D
DĆ2
Preset Words
Word
No. Description
2 Preset value A for output 0
3 Preset value B for output 0
4 Preset value A for output 1
5 Preset value B for output 1
7 Preset value A for output 2
8 Preset value B for output 2
9 Preset value A for output 3
10 Preset value B for output 3
12 Preset value A for output 4
13 Preset value B for output 4
14 Preset value A for output 5
15 Preset value B for output 5
17 Preset value A for output 6
18 Preset value B for output 6
19 Preset value A for output 7
20 Preset value B for output 7
Read-data Words
Word No. Bit No. Description
1 17 Status of output 7
16 Status of output 6
15 Status of output 5
14 Status of output 4
13 Status of output 3
12 Status of output 2
11 Status of output 1
10 Status of output 0
07 Loss-of-input-power bit - bit is set when
input power is lost; it is reset when power is
restored and bit 6 is reset.
Block-transfer-read Data
