Publication 1734-UM004F-EN-E - December 2012
Configure Your Module 23
Setting Parameters
The module name appears here.
Type a description here.
The module address appears
here. (This field is read-only.)
This dialog also shows the
module’s device identity.
These fields are read-only.
At any point, you can click here to
finish changing configuration
parameters.
IMPORTANT: If configuration
changes are made in
offline mode they do
not take effect until
the system goes
online.
Click the Device parameters tab to
get to the dialog for setting the
parameters.
This dialog appears after clicking the
Device parameters tab. If you want
the existing parameters uploaded
from the module, select Upload.
The following dialog then shows the
existing parameters set on the
module.
Use this pull-down menu to edit or view
the parameters. Available choices are:
POINTBus
Status
Configuration
