Publication 1756-UM525A-EN-P - June 2003 53
Using the 1756-HYD02 Module Features Chapter 4
Ellipsis button (. . .) Opens the Motion Group Properties dialog box for the Assigned Motion Group, where you can edit the
properties of the Assigned Motion Group.
If no Motion Group is assigned to this axis, this button is disabled.
New Group Opens the New Tag dialog box, where you can create a new Motion Group tag. This button is enabled only if
you have not created a Motion Group tag.
Module Selects and displays the name of the motion module to which the axis is associated.
Displays if the axis is not associated with any motion module.
Module Type This read-only field displays the type of motion module, if any, associated with the axis.
Displays if the axis is not associated with any motion module.
Channel Selects and displays the channel–either 0 or 1–to which the axis is assigned.
Disabled when the axis is not associated with any motion module.
Feature: Definition:
