Rockwell Automation Publication 1738-UM005A-EN-P - July 2013 81
Specifications Appendix A
EtherNet Communication The 1738-AENT/B adapter modules have the following EtherNet
communication specifications.
Environmental
Specifications 1738-AENT/B EtherNet/IP Adapter modules have the following environmental
specifications.
POINTBus output current, max 5V DC @ 1.0A
Auxiliary power cable
(1)
Standard cordset (single-ended), for example Allen-Bradley part
number 889N-F4AFC-6F or 889N-R4AFC-6F.
Standard patchcord (double-ended), for example, Allen-Bradley part
number 889N-F4AFNU-6F or 889N-F4AFNV-6F.
Interruption Output voltage stays within specifications when input drops out for
10 ms @ 10V with max load
(1) Refer to publication M117-CA001A-EN-P for more information.
Power Supply Specifications
Attributes Description
EtherNet Communication Specifications
Attributes Description
Ethernet communication rate 10/100 Mbits/s, half or full-duplex
Ethernet ports 1
Ethernet network topologies
supported Star, Tree
Ethernet connectors M12, D code, female, with Ethernet keying
Ethernet cable Category 5:
shielded or unshielded
Environmental Specifications
Attributes Description
Temperature, operating IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20...60 °C (-4...140 °F)
Temperature, nonoperating IEC60068-2-1 (Test Ab, Unpackaged Nonoperating Cold)
IEC60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat)
IEC60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock):
-40...85 °C (-40...185 °F)
Temperature, surrounding air,
max 60 °C (140 °F)
Relative humidity IEC 60068-2-30 (Test Db, Unpackaged Damp Heat):
5...95% noncondensing
Vibration IEC 60068-2-6 (Test Fc, Operating):
5 g @ 10...500 Hz
Shock, operating IEC60068-2-27 (Test Ea, Unpackaged Shock):
30 g
