6 – troubleshoot the adapter, Status indicators for armorpoint i/o adapters, Troubleshoot the adapter – Rockwell Automation 1738-AENT, Series B ArmorPOINT I/O Dual Port EtherNet/IP Adapters User Manual User Manual
Page 87: Interpret the status indicators, Chapter
Rockwell Automation Publication 1738-UM005A-EN-P - July 2013
75
Chapter
6
Troubleshoot the Adapter
This chapter describes the different status indicators available in the
1738 ArmorPOINT I/O EtherNet/IP adapter and how to interpret these
indicators to help troubleshoot the module. The following table lists where to
find specific information
Interpret the Status
Indicators
The 1738 ArmorPOINT I/O EtherNet/IP adapters have the following status
indicators:
•
Module Status,
•
Network Activity, Network Status,
•
POINTBus Status
•
System Power
•
Adapter Power
Status Indicators for ArmorPOINT I/O Adapters
The following describes the status indicators on the 1738-AENT.
Topic
Page
Interpret the Status Indicators
Status Indicators for ArmorPOINT I/O Adapters
1738-AENT
Series B
EtherNet I/P
Adapter
Status
Network
Activity
Network
Status
PointBus
Status
System
Power
Adapter
Power
X100
X10
X1
conformance tested
™
PWR
P
A
D
D
R
E
S
S
I
System Power
Adapter Power
Adapter Status
Network Activity
Network Status
POINTBus Status
43798
