Chapter
2
Install Your ArmorPOINT I/O Adapter
Overview This chapter describes how to install and wire your module. This chapter includes
the following topics:
Topic Page
Mount the Adapter and I/O Base 10
Install the ArmorPOINT I/O Modules 11
Remove an ArmorPoint I/O Module 11
Wire an ArmorPOINT I/O Adapter 12
Chapter Summary 12
ATTENTION: To comply with the CE Low Voltage Directive (LVD), this
equipment must be powered from a source compliant with the
following:
Safety Extra Low Voltage (SELV) or Protected Extra Low Voltage (PELV).
ATTENTION: This product is intended to be mounted to a well-
grounded mounting surface such as a metal panel. Additional
grounding connections from the power supply's mounting tabs or DIN
rail (if used) are not required unless the mounting surface cannot be
grounded. Refer to Industrial Automation Wiring and Grounding
Guidelines, Rockwell Automation publication
1770-IN041 , for
additional information.
ATTENTION: If this equipment is used in a manner not specified by the
manufacturer, the protection provided by the equipment may be
impaired.
ATTENTION: To comply with the CE Low Voltage Directive (LVD), this
equipment must be powered from a source compliant with the
following:
Safety Extra Low Voltage (SELV) or Protected Extra Low Voltage (PELV).
