Common Techniques Used
in this Manual
The following conventions are used throughout this manual:
•
Bulleted lists such as this one provide information, not procedural steps.
•
Numbered lists provide sequential steps or hierarchical information.
•
Italic type is used for emphasis.
Rockwell Software products contain extensive tutorials and help screens. We
recommend that you use these tutorials and help screens to learn about the
products.
For more information about Rockwell Software products, visit the Rockwell
Software website at
.
About the Example Applications
This manual presents two example applications that demonstrate the procedures
for configuring and communicating with ArmorPOINT I/O modules using the
ArmorPOINT I/O adapter. We intend the example applications as building
blocks to help you get your own system up and running. We recommend that you
set up and run the example applications and use them as guides.
Here is the type of system you’ll be setting up.
