Rockwell Automation 1395 DC Drive, 800-1250 Hp, FRN 5.XX-9.30 - Manual (Page 43)

Chapter 3
Functional Description
3-10
Table 3.B
Control Logic Source Parameters
Number
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
Name
Logic Status
Drive Fault
Pre Ramp Vel Ref
Ramp Vel Ref
Final Vel Ref
Arm Voltage Fdbk
Velocity Fdbk
Position Fdbk
Vel Feed Fwd
Position Error
Torque Command
Arm Current Ref
Arm Current Fdbk
Arm Cur PI Out
Arm Cur Fire Ang
Flux Command
AC Line Voltage
Fld Current Ref
Fld Current Fdbk
Proc Trim Output
Function
16 bit word used to indicate the present operating condition of
the drive.
16 bit word used to indicate fault conditions in the drive.
Velocity reference output from the Velocity Reference Control
Velocity reference output from the Ramp Control.
Velocity Reference input to the Velocity PI Control which is the
sum of the output from the Ramp Control, Process Trim and
Droop functions.
Actual armature voltage.
Final velocity feedback used as input to the Velocity PI
Control.
Final position feedback used as input to the position control
portion of the Velocity PI Control
Error term used in proportional path of the velocity PI regulator
Error between position reference and position feedback
(P107)
Internal Torque Reference
Torque command scaled by flux command.
Actual armature current.
Output of the Armature Current PI Control
P113 converted to an angle reference modified by
discontinuous current adaptation when operating in
discontinuous current range.
Output of the field flux control.
Actual three-phase input line voltage.
Flux command scaled by the Field Flux Linearization Table.
Actual field current.
Output of velocity trim control.
Linking Source to Sink Parameters
In order for information from a Source parameter to be input to a Sink
parameter, a link must be made between the two desired parameters. For
example, to send the information from Parameter 400 (first Source
parameter associated with Port A) to Parameter 151 (pre-defined as Logic
Cmd 2, input), then Parameter 151 must be linked to Parameter 400.
Linking of Parameter 151 to 400 is shown in Figure 3.3.
Linking of parameters is accomplished using the drive Setup Mode on the
Programming Terminal. The drive will allow a total of 20 links to be
made. There are two fixed links that cannot be altered or reconfigured,
thereby allowing a maximum of 18 user configurable links. Linking of
Sources to Sinks is referred to as “Configuring” the drive. For a complete
description of how to use the Programming Terminal to configure the
drive, refer to the Programming Terminal Instruction Manual. It should be
