Chapter 6
Start–Up
6-9
Table 6.I
Basic Parameters — Feedback Scaling
Parm
739
740
Parameter Name
K Arm Volts
K AC Volts
Numerical value used to scale the armature voltage feedback.
Values to be entered at this time are:
6414 = for 150 – 300 rated arm voltage
12321 = for 300 – 575 rated arm voltage
16017 = for 575 – 700 rated arm voltage
Description
Numerical value used to scale the incoming AC line voltage
feedback. Values to be entered at this time are:
3872 = for 150 – 300 rated AC line voltage
7473 = for 300 – 575 rated AC line voltage
9747 = for 575 – 660 rated AC line voltage
Table 6.J
Set-Up Parameters
Parm
614
620
623
624
626
627
628
630
631
632
653
657
658
665
666
667
672
673
676
704
705
706
707
708
709
710
711
717
Parameter Name
Armature Resistance
System Reset Select
Fault Select
Maintained Start
Jog Ramp Enable
Flux Mode Select
Process Trim Select
Fault Report
Velocity Feedback Filter Select
Warning Select
Desired Contour
Droop Percent
Droop Filter
Start Taper Speed
End Taper Speed
Minimum Taper Current
KI Flux
KP Flux
Field Flux Reference
At Speed 1
At Speed 2
At Speed 3
At Speed 4
At Speed 5
Up to Speed Tolerance
Zero Speed Tolerance
Jog Dwell
Process Trim Low Limit
Value
Motor Characteristics
Application
Application
Application
Application
Application
Application
Application
Application
Application
Application
Application
Application
Motor Commutation Limit
Motor Commutation Limit
Motor Commutation Limit
Application
Application
Application
Application
Application
Application
Application
Application
Application
Application
Application
Application
Classification
