Chapter 1
Introduction, Inspection & Storage
1-3
•
Node Adapter Board
The board allows the Bulletin 1395 to be controlled using an
Allen-Bradley PLC
Programmable Controller from the PLC3
or
PLC5
family. This board connects directly to the RIO scanner
•
Multi-Communications Adapter Board
Contains the hardware necessary to connect the 1395 to
Allen-Bradley’s RIO or Data Highway Plus
communication links.
Accessories
•
Isolation Transformers, AC Line Reactors.
•
Program Terminals.
Receiving
It is the responsibility of the user to thoroughly inspect the equipment
before accepting the shipment from the freight company. Check the
item(s) received against the purchase order. If any items are obviously
damaged, it is the responsibility of the user not to accept delivery until
the freight agent has noted the damage on the freight bill. Should any
concealed damage be found during unpacking, it is again the
responsibility of the user to notify the freight agent. The shipping
container must be left intact and the freight agent should be requested to
make a visual inspection of the equipment.
Unpacking
Remove all packing material, wedges, or braces from within and around
the drive. Remove all packing material from the cooling fans (when
equipped) and the heat sink.
IMPORTANT: Before the installation and start-up of the drive, a
general inspection of the mechanical integrity (i.e. loose parts, wires,
connections, etc.) should be made.
Inspection
After unpacking, check the item(s) nameplate catalog number against the
purchase order.
Storing
The drive should remain in its shipping container prior to installation. If
the equipment is not to be used for a period of time, it must be stored
according to the following instructions in order to maintain warranty
coverage:
•
Store in a clean, dry location.
•
Store within an ambient temperature range of 0
°
to 65
°
C (32
°
to
149
°
F).
•
Store within a relative humidity range of 5% to 95%,
non-condensing.
•
Do not store equipment where it could be exposed to a corrosive
atmosphere.
•
Do not store equipment in a construction area.
