Appendix B
QoS Object — CLASS CODE 0x48
The following class attributes will be supported for the QoS object.
Table 49 - QoS Object Class Attributes
A single instance (Instance 1) will be supported.
Table 50 - QoS Object Instance
The following common services will be implemented for the QoS object.
Table 51 - QoS Object Common Services
Non-Volatile Storage Object — CLASS CODE 0xA1
The following instances of the Non-Volatile Storage object will be supported.
Table 52 - Non-Volatile Storage Object Instances
Attribute ID Access Rule
Name
Data Type Value
1
Get
Revision UINT
1
Attribute ID Access Rule
Name
Data Type Value
1
Set
802: 1Q Tag Enable USINT
0=Disable (default)
1=Enable
4
Set
DSCP Urgent
USINT
Default=55
5
Set
DSCP Schedule
USINT
Default=47
6
Set
DSCP High
USINT
Default=43
7
Set
DSCP Low
USINT
Default=31
8
Set
DSCP Explicit
USINT
Default=27
Service Code
Implemented for:
Service Name
Class
Instance
0x0E
Yes
Yes
Get_Attribute_Single
0x10
No
Yes
Set_Attribute_Single
NVS Object Instance
Entity to be Updated
1
EtherNet/IP Module Application Code
2
EtherNet/IP Module Boot Code
3
EtherNet/IP Module FPGA Image
