Rockwell Automation 193-DNENCATR EtherNet/IP Communications Auxiliary User Manual User Manual
Page 76

76
Rockwell Automation Publication 193-UM014B-EN-P December 2011
Chapter 9
Table 16 - Parameter 8 — SL Entry Size
Table 17 - Parameter 9 — Device Keys
Table 18 - Parameter 10 — Scanlist Config
Table 19 - Parameter 11 — ADR Record
Table 20 - Parameter 12 — ADR Enable
Description
Access Rule
Data Type Units
Value
Min.
Max. Default
Defines the number of bytes
to be scanned for I/O data
from each DeviceNet Device.
Get/Set
USIN T
Bytes
1
50
8
Description
Access Rule
Data Type
Units
Value
Min.
Max. Default
Determines how electronic
keying will be performed.
Get/Set
USIN T
—
0
63
7
Bit
0
Device Type
2
Product Code
4
Minor Revision
1
Vendor
3
Major Revision
5
Minor of Higher
Description
Access Rule
Data Type Units
Value
Min.
Max. Default
Triggers the building of a new
DeviceNet scan list.
0 = Ready
1 = Build Scan List
Get/Set
BOOL
—
0
1
0
Description
Access Rule
Data Type Units
Value
Min.
Max. Default
Triggers the recording of
configuration parameters from
devices in the DeviceNet scan list
to be used for Automatic Device
Replacement.
0 = Ready
1 = Record Parameters
Get/Set
BOOL
—
0
1
0
Description
Access Rule
Data Type Units
Value
Min.
Max. Default
Enables Automatic Device
Replacement.
0 = Disable
1 = Enable
Get/Set
BOOL
—
0
1
0
