Rockwell Automation 193-DNENCATR EtherNet/IP Communications Auxiliary User Manual User Manual
Page 83

Rockwell Automation Publication 193-UM014B-EN-P December 2011
83
Chapter 10
DeviceNet
Network Status
(NS)
None
—
The EtherNet/IP
Communications Auxiliary is
not receiving power.
Check the DeviceNet cable
connections and verify that
24V DC exists between the red
and black terminals.
Green, Red,
Not Illuminated
Flashing
(once)
Normal
This is a normal power-up
sequence.
Green
Flashing
The EtherNet/IP
Communications Auxiliary is
not configured to scan any
DeviceNet slave devices.
Check the DeviceNet scan list
for the correct scanner
configuration.
Green
Solid
Normal operating state and
the EtherNet/IP
Communications Auxiliary is
scanning DeviceNet slave
devices.
No action is required.
Red
Flashing
One or more DeviceNet
connections timed out.
Reset the EtherNet/IP
Communications Auxiliary.
Red
Solid
Diagnostics test failed on
power-up/reset. An internal
fault exists.
Cycle power to the unit. If the
fault still exists, replace the
unit.
Duplicate DeviceNet module
address exists. Two modules
cannot have the same address.
Change the MAC address to a
valid setting and reset the
device.
A fatal communication error
occurred.
Check DeviceNet media for
proper installation.
Module Status
None
—
The EtherNet/IP
Communications Auxiliary is
not receiving power.
Check the DeviceNet cable
connections and verify that
24V DC exists between the red
and black terminals.
Green, Red,
Not Illuminated
Flashing
(once)
Normal
This is a normal power-up
sequence.
Green
Flashing
The EtherNet/IP
Communications Auxiliary is
proper;y scanning DeviceNet
slave devices, but it is not
being scanned by the
EtherNet/IP master.
Check the Ethernet scan list
for the correct scanner
configuration.
Green
Solid
Normal operating state, the
EtherNet/IP Communications
Auxiliary is scanning
DeviceNet slave devices, and
is allocated to its master.
No action is required.
Red
Flashing
One or more DeviceNet or
EtherNet/IP connections timed
out.
Reset the EtherNet/IP
Communications Auxiliary.
The EtherNet/IP
Communications Auxiliary is
not configured to scan any
DeviceNet slave devices.
Check the DeviceNet scan list
for correct scanner
configuration.
Red
Solid
Diagnostics test failed on
power-up/reset.
Cycle power to the device. If
the fault still exists, replace
the device.
Link
Link (front)
Link (back)
None
—
The EtherNet/IP
Communications Auxiliary is
not properly connected to an
Ethernet network.
Check the Ethernet cabling to
make sure it is properly
installed.
Green
Flashing
The Ethernet network is
properly connected.
No action is required.
Green
Solid
Communications are occurring
on the Ethernet network.
No action is required.
Status LED
Color
State
Possible Cause
Corrective Action
