Rockwell Automation 193-DNENCATR EtherNet/IP Communications Auxiliary User Manual - Manual (Page 16)

16 Rockwell Automation Publication 193-UM014B-EN-P December 2011
Chapter 2
Table 3 - EtherNet/IP Network Parameters for DNS Addressing
Setting the IP Network
Address An EtherNet/IP Communications Auxiliary ships with DHCP enabled. You can
set the network Internet Protocol (IP) address by using:
• the EtherNet/IP node address selection switches,
• a Bootstrap Protocol (BOOTP)/Dynamic Host Configuration Protocol
(DHCP) server (e.g., the Rockwell Automation BOOTP-DHCP Server
Utility, which is included with Rockwell Software’s RSLinx™ Classic
software), OR
• a web browser and MAC scanner software.
EtherNet/IP Node Address Selection Switches
The EtherNet/IP Communications Auxiliary comes with three node address
selection switches that allow the user to select the last octet for the IP address
192.168.1.xxx.
Network Parameter Description
Host Name A host name is part of a text address that identifies the
module. The full text address of a module is:
host_name.domain_name.
Domain Name A domain name is part of a text address that identifies the
domain in which the module resides. The full text address of a
module is: host_name.domain_name. The domain name has a
48-character limit.
Primary DNS Server Address This identifies any DNS servers used in the network. You must
have a DNS server configured if you specify an SMTP server
with a name. The DNS server converts the domain name or
host name to an IP address that can be used by the network.
For more information on DNS addressing, refer to
page 23 .
Secondary DNS Server Address
