Rockwell Automation Publication 750COM-UM002B-EN-P - October 2012 49
Configuring the I/O Chapter 4
25. From the File menu, choose Save.
If this is the first time you saved the project, the Save As dialog box appears.
a. Navigate to a folder.
b. Type a file name.
c. Click Save to save the configuration as a file on your computer.
26. When configuring the I/O for additional PowerFlex 750-Series drives on
the network, repeat steps 14 through 25.
Setting Datalinks in the Drive (Optional)
After configuring the 1756-DNB scanner, Datalinks (if used) must be set to
parameters that are appropriate for your application.
Use the 20-HIM-A6 or 20-HIM-C6S HIM, or another drive configuration tool
such as Connected Components Workbench, DriveExplorer, DriveExecutive
software to set the Datalinks in the drive. For this example, the following
Datalink values are used.
IMPORTANT When all Datalinks in each drive are used (18 DINTs of I/O per drive), a
maximum of 6 PowerFlex 750-Series drives can be mapped. This is due
to the amount of I/O available in the 1756-DNB scanner, which is a
maximum of 124 DINTs.
Option Module Host Parameter Value Description
01 - [DL From Net 01] 370 Points to drive Par. 370 - [Stop Mode A]
02 - [DL From Net 02] 371 Points to drive Par. 371 - [Stop Mode B]
03 - [DL From Net 03] 535 Points to drive Par. 535 - [Accel Time 1]
04 - [DL From Net 04] 536 Points to drive Par. 536 - [Accel Time 2]
05 - [DL From Net 05] 537 Points to drive Par. 537 - [Decel Time 1]
06 - [DL From Net 06] 538 Points to drive Par. 538 - [Decel Time 2]
07 - [DL From Net 07] 539 Points to drive Par. 539 - [Jog Acc Dec Time]
08 - [DL From Net 08] 556 Points to drive Par. 556 - [Jog Speed 1]
09 - [DL From Net 09] 557 Points to drive Par. 557 - [Jog Speed 2]
10 - [DL From Net 10] 571 Points to drive Par. 571 - [Preset Speed 1]
11 - [DL From Net 11] 572 Points to drive Par. 572 - [Preset Speed 2]
12 - [DL From Net 12] 573 Points to drive Par. 573 - [Preset Speed 3]
13 - [DL From Net 13] 574 Points to drive Par. 574 - [Preset Speed 4]
14 - [DL From Net 14] 575 Points to drive Par. 575 - [Preset Speed 5]
15 - [DL From Net 15] 576 Points to drive Par. 576 - [Preset Speed 6]
16 - [DL From Net 16] 577 Points to drive Par. 577 - [Preset Speed 7]
17 - [DL To Net 01] 370 Points to drive Par. 370 - [Stop Mode A]
18 - [DL To Net 02] 371 Points to drive Par. 371 - [Stop Mode B]
19 - [DL To Net 03] 535 Points to drive Par. 535 - [Accel Time 1]
