NET A Status Indicator
This red/green bicolor LED indicates the status of the network connection to the
option module as shown in the table below.
Viewing Option Module
Diagnostic Items
If you encounter unexpected communications problems, the option module’s
diagnostic items may help you or Rockwell Automation personnel troubleshoot
the problem. Option module diagnostic items can be viewed with any of these
drive configuration tools:
• PowerFlex 20-HIM-A6 or 20-HIM-C6S HIM
• Connected Components Workbench software, version 1.02 or later
• DriveExplorer software, version 6.01 or later
• DriveExecutive software, version 5.01 or later
For details on viewing diagnostic items using the HIM, see the PowerFlex 20-
HIM-A6/-C6S HIM (Human Interface Module) User Manual, publication
Status
Cause
Corrective Actions
Off
The option module is not powered or is not
properly connected to the network. The link is
inactive.
• Securely connect the option module to the drive and
connect it to the network with a CAT5 cable.
• Correctly connect the network cable to the option
module’s RJ45 Ethernet connector.
• Apply power to the drive.
Flashing Red
Any error in packet validation and/or execution is
considered a network configuration error.
Re-configure the option module.
Steady Red
Any failure in self-test on the external Ethernet
controller is considered a network controller
error.
• Cycle power to the drive.
• Re-configure the BACnet Client.
Steady Green
The option module is properly connected and
communicating on the network.
No action required.
Table 4 - Option Module Diagnostic Items
No.
Name
Description
1
Common Logic Cmd
The present value of the Common Logic Command being transmitted to the drive by this option module.
2
Prod Logic Cmd
The present value of the Product Logic Command being transmitted to the drive by this option module.
3
Reference
The present value of the Reference being transmitted to the drive by this option module.
4
Common Logic Sts
The present value of the Common Logic Status being received from the drive by this option module.
5
Prod Logic Sts
The present value of the Product Logic Status being received from the drive by this option module.
6
Feedback
The present value of the Feedback being received from the drive by this option module.
7
DPI Rx Errs
The present value of the DPI CAN Receive error counter register.
8
DPI Rx Errs Max
The maximum value of the DPI CAN Receive error counter register.
9
DPI Tx Errs
The present value of the DPI CAN Transmit error counter register.
10
DPI Tx Errs Max
The maximum value of the DPI CAN Transmit error counter register.
11
Boot Flash Count
The number of times the boot firmware in this option module has been updated.
12
App Flash Count
The number of times the application firmware in this option module has been updated.
