BLADEOS 6.5.2 Application Guide
BMD00220, October 2010 Chapter 20: OSPF 285
Configuring Plain Text OSPF Passwords
To configure simple plain text OSPF passwords on the switches shown in Figure 33 use the
following commands:
1. Enable OSPF authentication for Area 0 on switches 1, 2, and 3.
2. Configure a simple text password up to eight characters for each OSPF IP interface in Area 0 on
switches 1, 2, and 3.
3. Enable OSPF authentication for Area 2 on switch 4.
4. Configure a simple text password up to eight characters for the virtual link between Area 2 and
Area 0 on switches 2 and 4.
RS G8124(config-router-ospf)# area 0 authentication-type password
RS G8124(config-router-ospf)# exit
RS G8124(config)# interface ip 1
RS G8124(config-ip-if)# ip ospf key test
RS G8124(config-ip-if)# exit
RS G8124(config)# interface ip 2
RS G8124(config-ip-if)# ip ospf key test
RS G8124(config-ip-if)# exit
RS G8124(config)# interface ip 3
RS G8124(config-ip-if)# ip ospf key test
RS G8124(config-ip-if)# exit
RS G8124(config)# router ospf
RS G8124(config-router-ospf)# area 2 authentication-type password
RS G8124(config-router-ospf)# area-virtual-link 1 key blade
