BLADEOS 6.5.2 Application Guide
184 Chapter 13: VMready BMD00220, October 2010
VMready Configuration Example
This example has the following characteristics:
A VMware vCenter is fully installed and configured prior to VMready configuration and
includes a “
bladevm ” administration account and a valid SSL certificate.
The distributed VM group model is used.
The VM profile named “Finance” is configured for VLAN 30, and specifies NIC-to-switch
bandwidth shaping for 1Mbps average bandwidth, 2MB bursts, and 3Mbps maximum band-
width.
The VM group includes four discovered VMs on switch server ports 1 and 2, and one static
trunk (previously configured) that includes switch uplink ports 3 and 4.
1. Define the server ports.
2. Enable the VMready feature.
3. Specify the VMware vCenter IPv4 address.
When prompted, enter the user password that the switch must use for access to the vCenter.
4. Create the VM profile.
RS G8124(config)# system server-ports port 1-2
RS G8124(config)# virt enable
RS G8124(config)# virt vmware vmware vcspec 172.16.100.1 bladevm
RS G8124(config)# virt vmprofile Finance
RS G8124(config)# virt vmprofile edit Finance vlan 30
RS G8124(config)# virt vmprofile edit Finance shaping 1000 2000 3000
