BLADEOS 6.5.2 Application Guide
180 Chapter 13: VMready BMD00220, October 2010
VMready Information Displays
The G8124 can be used to display a variety of VMready information.
Note – Some displays depict information collected from scans of a VMware vCenter and may not
be available without a valid vCenter. If a vCenter is assigned (see “Assigning a vCenter” on
page 172 ), scan information might not be available for up to two minutes after the switch boots or
when VMready is first enabled. Also, any major changes made through the vCenter may take up to
two minutes to be reflected on the switch unless you force an immediate vCenter scan (see
“vCenter
Scans” on page 173 .
Local VE Information
A concise list of local VEs and pre-provisioned VEs is available with the following ISCLI
privileged EXEC command:
Note – The Index numbers shown in the VE information displays can be used to specify a
particular VE in configuration commands.
RS G8124# show virt vm
IP Address VMAC Address Index Port VM Group (Profile)
---------------- ----------------- ----- ------- ------------------
*172.16.46.50 00:50:56:4e:62:00 4 3
*172.16.46.10 00:50:56:4f:f2:00 2 4
+172.16.46.51 00:50:56:72:ec:00 1 3
+172.16.46.11 00:50:56:7c:1c:00 3 4
172.16.46.25 00:50:56:9c:00:00 5 4
172.16.46.15 00:50:56:9c:21:00 0 4
172.16.46.35 00:50:56:9c:29:00 6 3
172.16.46.45 00:50:56:9c:47:00 7 3
Number of entries: 8
* indicates VMware ESX Service Console Interface
+ indicates VMware ESX/ESXi VMKernel or Management Interface
