BLADEOS 6.5.2 Application Guide
BMD00220, October 2010 Chapter 8: Spanning Tree Protocols 125
RSTP Configuration Guidelines
This section provides important information about configuring RSTP. When RSTP is turned on, the
following occurs:
STP parameters apply only to STG 1.
Only STG 1 is available. All other STGs are turned off.
All VLANs, including management VLANs, are moved to STG 1.
RSTP Configuration Example
This section provides steps to configure RSTP.
Note – Rapid Spanning Tree is the default Spanning Tree mode on the G8124.
1. Configure port and VLAN membership on the switch.
2. Set the Spanning Tree mode to Rapid Spanning Tree.
3. Configure STP Group 1 parameters.
RS G8124(config)# spanning-tree mode rstp
RS G8124(config)# spanning-tree stp 1 enable
RS G8124(config)# spanning-tree stp 1 vlan 2
