OPERATION

Form # 169053

34

Model Year - 2009

6.12 TRANSPORTING MOWER

CONDITIONER

The R80 Windrower can be transported on
public roads by towing with a tractor or a truck.
Proceed to 6.12.1 Transporting With A Tractor.
or, 6.12.2 Transporting With A Truck.

CAUTION

Be aware of roadside obstructions,

oncoming traffic and bridges.

Travel speed should be such that

complete control and machine stability
are maintained at all times. Do not
exceed 20 mph (32 km/h). Reduce speed
for corners and slippery conditions.

When transporting on roads, use tractor

lights and mower conditioner flashing
amber and red tail-lights to provide
adequate warning to operators of other
vehicles.

Do not transport the mower conditioner

on a road or highway at night, or in
conditions, which reduce visibility, such
as fog or rain.

6.12.1 Transporting With A Tractor

If the windrower is in transport mode, proceed
as follows. Otherwise, see 6.12.3 Preparing
Windrower for Transport.

a. Hook-up mower conditioner to tractor. See 6.4

Mower Conditioner/Tractor Hook-up, for details
on attaching the mower conditioner to the
tractor.

NOTE

The hydraulic hoses do not need to be
attached to the tractor for towing. Ensure
they are securely stored on the APT.

NOTE

The PTO does not need to be attached for
towing purposes. If not attached, lower
hook (A), store driveline (B) on hook, and
remove forward half of driveline. Store
forward half in cab for transport.

b. Ensure that APT safety chain is properly

attached to towing vehicle. Provide only enough
slack in chain to permit turning.

c. Check local laws for width regulations and

lighting or marking requirements before
transporting on roads.

d. Do not exceed 20 mph (32 km/h).

6.12.2 Transporting With a Truck

CAUTION

Do not tow with a vehicle weighing less than
7500 lb (3400 kg). Ensure that the capacity
of the towing vehicle is sufficient to maintain
control.

If the windrower is in transport mode, proceed
as follows. Otherwise, see 6.12.3 Preparing
Windrower for Transport.

a. Store hydraulic hoses on the APT as shown

opposite.

b. Lower hook (A) and place driveline in hook.
c. Remove the forward half (B) of driveline and

store in truck for transport.

(continued next page)

A

B
