OPTIONS AND ATTACHMENTS

Form # 169053

119

Model Year - 2009

9 OPTIONS AND ATTACHMENTS

The following kits are available through your
MacDon dealer.

9.1 GAUGE ROLLER KIT

The gauge roller kit installs at either end of the
cutterbar and the rollers can be adjusted for
varying cutting height. The kit includes two roller
assemblies and attachment hardware. It is
available only for the 16 foot header.

9.2 SKID SHOE KIT

The skid shoe kit installs at either end of the
cutterbar and the shoes can be adjusted for
varying cutting height. The kit includes two skid
shoe assemblies and attachment hardware. It is
available only for the 16 foot header.

9.3 SKID PLATE LIFT KIT

The shoe lift kit consists of spacer assemblies
that attach to the existing skid shoes to increase
the ground clearance by approximately 2 inches
(51 mm). The kit includes four assemblies and
attachment hardware.

Refer to R80 Pull-Type Rotary Disc Mower
Conditioner Unloading & Assembly Instructions,
#169080 that is included with your shipment, for
installation details.

9.4 TALL CROP DIVIDER KIT

The tall crop dividers attach to the ends of the
header for clean crop dividing and reel entry in
tall crops. The kit includes left and right dividers
and attachment hardware.

9.5 CUTTERBAR REPAIR TOOL KIT

The cutterbar repair tool kit contains the
necessary tools for replacement of the cutterbar
idler gears. Refer to the Technical Service
Manual for instructions.

9.6 HYDRAULIC CENTER LINK KIT

This kit allows the header angle to be adjusted
hydraulically with a cylinder replacing the
standard mechanical link, and uses a separate
hydraulic circuit from the tractor. Installation
instructions are included with the kit.
