MacDon R80 Rotary Disc Pull-Type Windrower User Manual
Page 23
OPERATION
Form # 169053
21
Model Year - 2009
NOTE
Bushings (P) on pins can be removed to
suit hole size in tractor hitch arms.
d. Assemble PTO driveline male half (Q) onto PTO
shaft (R) on APT. Push male half so that PTO
shaft is at its fully compressed length.
e. Locate PTO shaft in hook (S).
Q
R
S
P
