4.14

Upper Cross Auger (UCA)

The UCA helps deliver very bulky crops across the header
onto the windrow.

Removable beater bars assist in delivering material
through the header opening, but if wrapping occurs, the
beater bars can be removed.

IMPORTANT:
The upper cross auger drive motor must be equipped
with a case drain kit when used on single draper drive
headers. See your MacDon Dealer for details.

Figure 4.66: Upper Cross Auger

4.14.1

Removing Beater Bars

To remove beater bars, follow these steps.

WARNING

Stop engine and remove key before removing plugged material from header. A child or even a pet could
engage the drive.

Lower header to ground, shut down engine, and
remove key.

169899

Revision A
