OPERATION
11. Remove pin (A), raise support (B) to position shown,
and reinsert pin (A).
IMPORTANT:
Ensure pin (A) engages the tube on the axle.
12. Swing brace (C) into position as shown and insert
brace into slot (D) behind cutterbar. Position brace so
that pin (E) engages hole in bracket (F). Right hand
wheel is now in Transport position.
13. Disengage the header cylinder lift stops.
14. Detach the header from the windrower. Refer to your
windrower operator’s manual for procedure.
15. Detach the header’s hydraulic and electrical
connections from the windrower. Refer to 5 Header
Attachment/Detachment, page 107 .
16. Start windrower and lower header to the ground.
Figure 4.94: Positioning Right Rear Wheel
Attaching Tow-Bar
The tow-bar consists of two sections which make storage and handling easier.
1. On the right side of the header, unhook rubber strap
(D) on cradle (A).
2. Remove clevis pin (C). Detach tube end from support
(B).
3. Replace clevis pin.
4. Lift inner half of tow-bar off of header, and place it near
the left side of the header.
Figure 4.95: Removing Tow-Bar
169899 101 Revision A
