BigStuff3 Pro SEFI System

Version 2.1 – February 2011

30. SPARK (F4 – “Quick Key”)

There are several ways to access the base Spark table. The quickest methods are to hit the F4 “Quick
Key” or left mouse click on the Spark Table icon, accessible from the main BigComm Screen. The
Main Tool Bar can also be used to access the Spark table. From the Main BigComm software screen
tool bar left click on Spark and the drop down screen will open.

31. Spark Table

The ellipse will move
throughout the Spark table
relative to the current RPM
& Load “operating point”

Spark Table Icon
