StRIAtED PAnEL PRoFILE
12" COVERAGE
C
2
3
/
8
" or 3"
w
/
CAp
16" COVERAGE
C
18" COVERAGE
C
24" COVERAGE
C
2
3
/
8
" or 3"
w
/
CAp
2
3
/
8
" or 3"
w
/
CAp
2
3
/
8
" or 3"
w
/
CAp
3" RIB HEIGHt
WEIGHt
PER SQ.
GAUGES
AcG
PVDF
BARE ALUM.
24 GA
TA13541
TA135XX
-
182 lbs
22 GA
TA23541
TA235XX
-
231 lbs
20 GA
TA33541
TA335XX
-
276 lbs
.032 AL
-
TA135XXA
TA13501A
90 lbs
.040 AL
-
TA235XXA
TA23501A
111 lbs
3" RIB HEIGHt
WEIGHt
PER SQ.
GAUGES
AcG
PVDF
BARE ALUM.
24 GA
TA13641
TA136XX
-
160 lbs
22 GA
TA23641
TA236XX
-
203 lbs
20 GA
TA33641
TA336XX
-
243 lbs
.032 AL
-
TA136XXA
TA13601A
79 lbs
.040 AL
-
TA236XXA
TA23601A
97 lbs
3" RIB HEIGHt
WEIGHt
PER SQ.
GAUGES
AcG
PVDF
BARE ALUM.
24 GA
TA13741
TA137XX
-
152 lbs
22 GA
TA23741
TA237XX
-
194 lbs
20 GA
TA33741
TA337XX
-
232 lbs
.032 AL
-
TA137XXA
TA13701A
75 lbs
.040 AL
-
TA237XXA
TA23701A
92 lbs
3" RIB HEIGHt
WEIGHt
PER SQ.
GAUGES
AcG
PVDF
BARE ALUM.
24 GA
TA13841
TA138XX
-
138 lbs
22 GA
TA23841
TA238XX
-
176 lbs
20 GA
TA33841
TA338XX
-
211 lbs
.032 AL
-
TA138XXA
TA13801A
67 lbs
.040 AL
-
TA238XXA
TA23801A
83 lbs
2
3
/
8
" RIB HEIGHt
WEIGHt
PER SQ.
GAUGES
AcG
PVDF
BARE ALUM.
24 GA
TA13141
TA131XX
-
172 lbs
22 GA
TA23141
TA231XX
-
218 lbs
20 GA
TA33141
TA331XX
-
261 lbs
.032 AL
-
TA131XXA
TA13101A
86 lbs
.040 AL
-
TA231XXA
TA23101A
105 lbs
2
3
/
8
" RIB HEIGHt
WEIGHt
PER SQ.
GAUGES
AcG
PVDF
BARE ALUM.
24 GA
TA13241
TA132XX
-
152 lbs
22 GA
TA23241
TA232XX
-
194 lbs
20 GA
TA33241
TA332XX
-
232 lbs
.032 AL
-
TA132XXA
TA13201A
75 lbs
.040 AL
-
TA232XXA
TA23202A
92 lbs
2
3
/
8
" RIB HEIGHt
WEIGHt
PER SQ.
GAUGES
AcG
PVDF
BARE ALUM.
24 GA
TA13341
TA133XX
-
146 lbs
22 GA
TA23341
TA233XX
-
186 lbs
20 GA
TA33341
TA333XX
-
222 lbs
.032 AL
-
TA133XXA
TA13301A
72 lbs
.040 AL
-
TA233XXA
TA23301A
88 lbs
2
3
/
8
" RIB HEIGHt
WEIGHt
PER SQ.
GAUGES
AcG
PVDF
BARE ALUM.
24 GA
TA13441
TA134XX
-
133 lbs
22 GA
TA23441
TA234XX
-
170 lbs
20 GA
TA33441
TA334XX
-
203 lbs
.032 AL
-
TA134XXA
TA13401A
65 lbs
.040 AL
-
TA234XXA
TA23401A
80 lbs
*panel weight includes the panel cap and panel clips at a 48" spacing
3" rib height and 24" wide panels currently not available
