2. Design and description
2.1 Construction
1
2
3
4
5
6
7
8
10
9
11
Fig. 2 HPP Constant climate chamber
1 Controller/user interface (see page 23 )
2 Set key
3 Main switch / push-turn control (see page 23 )
4 Door seal
5 Interior seal
6 Chamber fan
7 Sliding shelf
8 Heating ribs
9 Nameplate (underneath door)
10 Door knob
11 Card reader
