Advanced functions
7.4 Heat output distribution ( BALANCE)
For constant climate chambers HPP 749, application-specific correction of the heat output
distribution (BALANCE) is possible between the upper and lower heating groups in the SETUP
(setting: see page 42 ). The adjustment range is from –50 % to +50 %.
Setting 0 % restores the heating output distribution factory settings.
upper heat output upper heat output
lower heat output
-20%
lower heat output
+30%
Fig. 26
Left: The –20 % setting causes the lower heating groups to emit 20 % less heat than the upper
heating groups.
Right: The +30 % setting causes the lower heating groups to emit 30 % more heat than the
upper heating groups.
