Memmert HPP 108/749 Constant climate chamber (Generation 2003) - Manual (Page 31)

31
Operation and control
loop
t3
t4 t2
t1
on
off
Mo Tu We Th Fr Sa Su
3
4
2
1
STERI DEFRO
mb
IN 1 IN 2 OUT
MIN
AUTO
MAX
°C °C
% rh
h
PRINT SETUP
8. Light intensity during the first ramp segment (optional):
Adjustment range: 0 % to 100 % in steps of 10%. In the example shown: Light intensity 60 %
(six bars are lit up).
The interior lighting can only be activated at a working temperature of up to 40 ºC.
loop
t3
t4 t2
t1
on
off
Mo Tu We Th Fr Sa Su
3
4
2
1
STERI DEFRO
mb
IN 1 IN 2 OUT
MIN
AUTO
MAX
°C °C
% rh
h
PRINT SETUP
IN 2 OUT
%
9. Setpoint humidity/humidity to end of ramp segment
Adjustment range: 10 to 90 % rh. In the example shown: humidity 80.0 % rh.
Each ramp must be completed with a close statement connecting the ramp to the next one.
These commands thus control the programme sequence:
loop
t3
t4 t2
t1
on
off
Mo Tu We Th Fr Sa Su
3
4
2
1
STERI DEFRO
mb
IN 1 IN 2 OUT
MIN
AUTO
MAX
°C °C
% rh
h
PRINT SETUP
10. Close statement of the ramp segment
Setting: NEXT, SPWT (T), SPWT (H), SPWT (TH), LOOP, HOLD, END (shown: command end, see also
chapter 5.6.6 " Close statements for ramp segments ").
loop
t3
t4 t2
t1
on
off
Mo Tu We Th Fr Sa Su
3
4
2
1
STERI DEFRO
mb
IN 1 IN 2 OUT
MIN
AUTO
MAX
°C °C
% rh
h
PRINT SETUP
11. Programme write mode Leave EDIT
Turn push/turn control to the right until EXIT appears in the display, and press the SET key
briefly to confirm.
