Delivery, Transport and Setting Up
3.4.1 Setting up options
Read the assembly instructions for the respective accessory part.
Floor/table
The chambers may be placed on the floor. Constant climate chambers HPP 108 may be placed
on a table (work surface), if the table is flat and horizontal and able to bear the weight of the
constant climate chamber.
Base
The chamber can be placed on a base (available as an accessory) ( Fig. 7 ).
Stackable model (HPP 108 only)
Two constant climate chambers HPP 108 can be placed on top of one another. Please ensure
that the chamber with the lower working temperature is always used as the lower chamber:
Warning!
Danger through contact with electrical voltage. Remove the
mains plug if the chamber is already connected to the power
supply.
1. Remove the housing cover from the lower chamber.
2. Insert the drilling template (supplied with the foot alignment) into the overturned lid.
3. Mark the drilling point and drill with a 4.2 mm diameter drill bit.
4. Screw the foot alignments to the top of the lid with the screws and nuts supplied ( Fig. 8 ).
5. Put the covers back on.
Fig. 7
Base
Fig. 8
Attaching the foot alignments when two
chambers are placed on top of one another
